Photoinitiators

Photoinitators

A photoinitiator is a molecule that, when exposed to radiation, undergoes photodissociation to yield a reactive species (anions, cations, or free radicals).  These reactive species can initiate desired chemical reactions.  Most commonly, photoinitiators are used to induce polymerization of various compounds.

For over 40 years, Hampford Research Inc. has manufactured several types of photoinitiators.  Our story began with free radical photoinitiators based on the hexaarylbiimidazole (HABI) molecule.  Throughout the years we also developed a strong presence within the diaryliodonium salt photoacid generator market, as well as many other photoinitiators along the way.

Free Radical Photoinitiators

Free radical photoinitiators, typically referred to simply as photoinitiators (PIs), induce polymerization through double bonds.  They are commonly used in acrylate, methacrylate, styrene, and many other systems.  PIs are classified into two categories, Norrish type I and Norrish type II.  Norrish type I PIs are unimolecular.  Upon irradiation, type I PIs undergo homolytic cleavage, generating radical species.  Norrish type II PIs are bimolecular.  Type II PIs require the presence of a coinitiator from which to abstract a hydrogen atom, to generate free radicals.

HABI photoinitiators operate in a unique situation, as a cross between type I and II.  Upon irradiation, they split into two radicals like a type I PI.  Although, those lophyl radicals are highly stable and have low reactivity.  As a result, HABIs require an external hydrogen donor or chain-transfer agent, similar to a coinitiator, to increase their reactivity and induce polymerization, like a type II PI.  Hampford Research experts can help you choose the ideal combination for your application.

Through careful modification of the substituents on the aryl groups, HRI has been able to significantly improve the performance of HABIs into the LED wavelength range.  These innovative compounds resist oxygen inhibition and their high molecular weights make them ideal for applications where low migration characteristics are paramount.
Product NameFunctionCAS NumberHRI Prod. #
Camphorquinone (CQ)Photoinitiator type II, sensitizer10373-78-1FP5060
Benzil Dimethyl Ketal (BDK)Photoinitiator type I, sensitizer24650-42-8FP5067
Bis(trichlorofluoro) HABIFree radical photoinitiator, low migration2991098-03-2FP5414
DibromochalconePhotoinitiator, sensitizer, sensitizing dye611-91-6FP5080
o-Cl-HABI (BCIM)Free radical photoinitiator with outstanding heat stability, low migration7189-82-4FP5380
O-Ethoxy HABI Free radical photoinitiator, low migration, halogen free29864-18-4FP5385
9-PhenylacridinePhotoinitiator type II, sensitizer, sensitizing dye602-56-2FP5400
TCDM-HABIFree radical photoinitiator, low migration, optimized for use with 365 and 385 nm LED lamps100486-97-3FP5450
TMCH (4-MTD)Photoinitiator type I, free radical generator3274-12-2FP5510

Photoacid Generators

Photoacid generators (PAGs), aka cationic photoinitiators, are molecules that absorb UV or visible light to generate acid.  The generated acid initiates cationic polymerization.  The most common usage is for ring-opening polymerization, as in epoxy or oxetane resins.  Less commonly, PAGs are also used for addition polymerization, as is the case for vinyl ethers, as well as to induce cross-linking.

Hampford Research Inc. is a global supplier of iodonium-based and specialty photoacid generators.  These highly engineered compounds offer unmatched photo speed, solubility, and temperature stability for both LED and broad spectrum applications.

Product NameFunctionCAS NumberHRI Prod. #
Bis(4-cumyl)iodonium TetraphenylboratePhotoacid generator1158840-74-4FP5028
Bis(4-t-butylphenyl)iodonium TetraphenylboratePhotoacid generator131725-16-1FP5041
Bis(4-t-butylphenyl)iodonium ChloridePhotoacid generator5421-53-4FP5213
OPPIAsymmetric iodonium photoacid generator121239-75-6FP5386
BisDDI SbF6 70% Photoacid generator in reactive diluent71786-70-4FP5374
HPPI 5225Asymmetric iodonium photoacid generator139301-16-9FP5225
2,4,6-Trimethylpyridinium TosylateHigh-performance, specialty photoacid generator59229-09-3FP5552
